Flojet Spot-Spray Water Pump

Flojet Spot-Spray Water Pump

HTML Editor - Full Version

Flojet Spot spray pump, is the ideal spot spray pump for quad or small tow-behind agricultural spray rigs.

12 VDC, 60 PSI shut off, 7.6 LPM open flow, Santoprene diaphragm, Viton check valve, 3/8 NPT female ports straight NPT to 10mm hose. #91010006 right angle NPT to 10mm hose #91010005.

Code Image Product Details Stock Price Quantity Enquire
03501506B
Flojet Spot-Spray Water Pump
03501506B
12V, 7.6LPM, 60PSI
Stock Level:
Available
Stock Level:
Available
$316.05 Incl. GST
Enquire

Pump Design: Motor Operated 3 Chamber diaphragm

Motor Design: Permanent Magnet TENV (non-ventillated)

Voltage: 12 VDC

Amp Draw: 8 amp max for 12 VDC

Pump Head: Reinforced Polypropylene

Elastomers Diaphragm: Santoprene

Check Valve: EPDM or Viton

Max. Flow Rate: 2.0 GPM (7.6 LPM)

Maximum Pressure: 60 psi (4.1bar)

Duty Cycle: Intermittent

Weight: 3.4 lb (1.5 Kg)

Certifications: CE, NSF components

Port Size Inlet/outlet: 3/8" (9.52mm) NPTF
