Ultraflex Mechanical Cable Steering Helm - Rotary
T85 Rotary Steering helm with black bezel. A complete steering helm consists of steering helm and bezel. All stainless steel cable output ends. Corrosion resistant materials. Particularly suitable where clearance is limited. Lock-to lock steering wheel turns: approx. 3.
FEATURES AND TECHNICAL SPECIFICATIONS:
• All stainless steel cable output ends
• Corrosion resistant materials
• Particulary suitable where clearance is limited
• Lock-to lock steering wheel turns: approx. 3
• Stroke 228 mm (9”)
• Maximum allowable steering wheel diameter: 406 mm (16”)
• Minimum steering cable bend radius: 200 mm (7.9”)
• Minimal feedback
• Compact for mounting
• T85 steering system is not to be used on boats equipped with engines that exceed the maximum horsepower rating of the boat
• Available in package with ROTECH-V
• Exceeds EN 28848 safety standards
• Exceeds ABYC P17 safety standards
