Actisense NMEA 2000 Quick Network Block

Actisense NMEA 2000 Quick Network Block

This Actisense™ Quick Network Block (QNB-1) allows backbone networking connections to be made easy and fault-free on National Marine Electronics Association (NMEA) buses and networks.

The QNB-1 is two products in one, being compatible with both NMEA 0183 buses and NMEA 2000 networks.

Features:

  • High quality NMEA 2000 barrier strip connections
  • Diagnostic LEDs
  • Uses standard ATO fuses

Benefits:

  • One unit provides six NMEA 2000 drops
  • Power feed is split to enable longer networks
  • Separate fusing for split power feed provides an easy way to isolate network segments
  • Simple installation on Mini and Micro networks using bulk cable
  • Easy to mix & match NMEA 2000 with Raymarine STNG on opposite sides



Code Image Product Details Stock Price Quantity Enquire
QNB-1
Actisense NMEA 2000 Quick Network Block
QNB-1
NMEA 2000 Network 6 way block
Stock Level:
Low Stock
Stock Level:
Low Stock
$387.94 Incl. GST
