Raymarine DST810 Gen 2 Thru-hull Smart Triducer
The Raymarine DST810 Gen2 is a Smart Multisensor through-hull transducer that offers depth, speed, and temperature functions in one compact thru-hull fitting.
The low-profile retractable sensor computes accurate depth, speed, and temperature data and communicates on a single NMEA200 data cable.
The DST810 Gen2 also features an integrated vessel attitude sensor and Bluetooth technology that allows boaters a simple way to calibrate speed-through-water using Airmar’s CAST mobile app. The Gen2 paddle wheel design delivers improved speed accuracy from .3 to 45 knots.
The DST810 Gen2 features a SeaTalkng connector for networking with Raymarine instruments and multifunction displays.
| Material | Plastic |
| Max Depth (Ft) | 330 (100m) |
| Frequency (KHz) | 235 kHz |
| Beam Width | N/A |
| Records | Depth, Speed Temperature, Heel, Trim |
| Hull Material | Fibreglass / Aluminum |
| Cable Length (Ft/M) | 9.8ft/3m |
| Deadrise Angles | Up to 22° |
